Performance of Steel Fiber Reinforced Concrete Corbels

Abstract

Seven full-scale reinforced concrete corbel specimens were tested to study performance of steel fiber reinforced concrete corbels with and without fibers were investigated. The test variables were steel fiber content (Vf %) and shear span-to-depth ratio (a/d), which Constants of concrete compressive strength (fcu), area of main steel reinforcement (As) and presence of horizontal stirrups. Test results showed that, addition of steel fibers or/and horizontal stirrups improves both shear strength and ductility of the tested corbels, and results in a more ductile failure mode. The Experimental results observed that the ultimate strength of reinforced concrete corbels along with fibers can be predicted by adding the fibers contribution to strength using the shear friction equation to the ACI Building Code provisions. It is found that considerable improvement in ultimate shear strength and first crack in the corbels. This study shows that there is a considerable increase in the ultimate shear strength of steel fiber reinforced concrete corbels is obtained by the addition of steel fibers for a specific range and with a fiber content of 1,2 and3 percent, an increase in the shear strength was obtained and decrease shear span to depth ratio from 0.80 to 0.65.

Country : Egypt

1 Amin Saleh2 Ahmed Fathy3 Ahmed Farouk4 Moaz Nasser

  1. Professor, Structural Engineering Dept., Faculty of Engineering, Ain Shams University, Cairo, Egypt
  2. Associated Professor, Structural Engineering Dept., Faculty of Engineering, Ain Shams University, Cairo, Egypt
  3. Associated Professor, Structural Engineering Dept., Faculty of Engineering, Future University, Cairo, Egypt
  4. Demonstrator, Structural Engineering Dept., High Institute for Engineering & Technology, Al-Obour, Egypt

IRJIET, Volume 3, Issue 2, February 2019 pp. 22-27

Full Paper
Download

References

  1. Giuseppe Campione, Lidia La Mendola, and Maria Letizia Mangiavillano, "Steel Fiber-Rein forced Concrete Corbels: Experimental Behavior and Shear Strength Prediction", ACI Structural Journal, V. 104, No. 5, Sep.-Oct. 2007.
  2. Collins, M.P., and Michell, D., "Rational approach to shear design-the1984 Canadian code provisions" ACI Struct. J., V. 83, No. 6, 1986.
  3. Solanki,H., and Sabnis,G.M., "Reinforced concrete corbels-simplified" ACI Struct. J., V. 84, No. 5, 1987.
  4. Yong,Y., and Balaguru,P., "Behaviour of Reinforced High-Strength-Concrete Corbels" Journal of Structural Engineering, ASCE, V. 120, No. 4, 1994.
  5. Foster,S.J., Powell, R.E., and Selim,H. S., "Performance of high-strength concrete corbels" ACI Struct. J., V.93, No. 5, 1996.
  6. Foster,S.J., and Malik,A.R., "Evaluation of efficiency factor models used in strut-and-tie modeling of non flexural members" J.Struct.Eng.,Vo.128,No.5, 2002.
  7. Hwang,S., Lu,W., and Lee,H., "Shear strength prediction for reinforced concrete corbels" ACI Struct. J., V. 97, No. 4, 2000.
  8. Hwang,S., and Lee,H., "Strength prediction for discontinuity regions by softened strut and tie model" J. Struct. Eng., V. 128, No. 12, 2002.
  9. Russo,G., Venir,R., Pauletta,M., and Somma,G."Reinforced concrete corbels shear strength model and design formula" ACI Struct. J., V. 103, No.1, 2006.
  10. FattuhiNijadI., "SFRC Corbels Tests, " ACI Structural Journal,V.84,No.2, Mar.-Apr. 1987.
  11. HashimM.S.Abdul-Wahab, "Strength of Reinforced Concrete Corbels with Fibers, " ACI Structural Journal, V. 86, Nov.-Dec. 1989.
  12. Giuseppe Campione, "Performance of Steel Fibrous Reinforced Concrete Corbels Subjected to Vertical and Horizontal Loads" Journal of Structural Engineering, V. 135, No. 5, May. 2009.
  13. FattuhiNijad, "Reinforced Steel Fiber Concrete Corbels with Various Shear Span- to-Depth Ratios", ACI Materials Journal V. 86, No. 6, Nov-Dec 1989.
  14. ACIcommittee318. "Building Code Requirement for Reinforcement Concrete (ACI318-08)," American Concrete Institute, Detroit, 2008.
  15. Hagberg, Thore, "Design of Concrete Brackets; On the Application of the Truss Analogy", ACI Journal, Proceedings V. 80, No. 1, January1983
  16. Nevielle, J.Taub, "Resistance to shear Reinforced Concrete Beams", ACI Structural Journal, V.57, No. 6, November1960.
